CO2 Control System for Mushroom Growing Operations

Description

The CO2 Monitor & Controller for Mushroom Farms automatically exhausts grow room air when carbon dioxide (CO2) levels get too high and is ready to protect your crop from high concentrations.

• Accurate CO2 Control
• Simple to Install and Use
• Easy Fresh-Air Calibration

Features

• Easy to read display with all functions set from 3 push buttons
• Non-UV Emitting LED’s – no interference with the grow cycle
• IP54 Enclosure – cover during cleaning or washdown
• Default settings: Low Set Point – 800 ppm. High Set Point – 1,500 ppm

Specifications

• Measurement Range: 0-10,000ppm
• Sensing Technology: Non-dispersive Infrared (NDIR)
• Accuracy: ± 70ppm or ± 5% CO2
• Sensor Response Time: < 2 minutes
• Operating Temperature: 32° to 122° F
• Calibration: In-situ with fresh air
• Relay: One Relay output, Peak Current < 5A@ 250 VAC, SPST. Normally Open
• Sensor Life Expectancy: 15 years

Electrical

• Power: 110VAC Grounded US Plug Only
• Power Consumption:2 Watts Maximum
• Piggyback Cable: Peak Current < 5A @ 250 VAC

Warranty

• 1 year – see CO2Meter Terms and Conditions

Documents

Data Sheet (pdf)

Manual (pdf)

Change the Target CO2 Level
