Description
Model: M0198158
This wall mount LED display monitor measures and displays CO2 in ppm, temperature (°C / °F), relative humidity in % w/ high resolution 0.1 and indicates VOC concentration with color bar for good or poor air quality.
APPLICATION:
For air cleaners, VOC monitors and odor monitors, optimize ventilation and make necessary energy-saving arrangement, warehouse, chambers, incubator, laboratories, hospital, clean rooms, refrigerators and other critical areas.
FEATURES:
– The most modern and smart LED display measures CO2, VOC, Temperature and RH%
– Easy and simple to used for indoor air quality in public such as schools, hospital, transportation places, library, etc.
– Large LEDs simultaneously display CO2, Temp, RH or VOC condition w/ light bars fo easy to understand the air quality level
– VOC: light blue LED (good), yellow LED (fair), red LED (poor)
– CO2: green, yellow, red LEDs stands for good, fair and poor CO2 concentration respectively
– ABC (Automatic Baseline Correction) CO2 function is selectable with ON or OFF
– Manually calibration CO2 reading in 12 hours available
– Calibrate VOC under fresh air
– Switchable temperature unit (°C/°F)
– Powered by 12V AC/DC adaptor
– Made in Taiwan
SPECIFICATIONS:
– Parameter: CO2, VOC, Temperature and Relative Humidity
– Measurement Range
CO2: 0~5,000ppm
VOC: 6 bars
– Sensor:
CO2: NDIR
VOC: Semi-conductor metal dioxide
– CO2 Resolution: 1 ppm
– Alarm: Audible
– Temperature Measurement
Range: 0~50°C (32~122°F)
Accuracy: ±1.0°C/2.0°F or ±1.5°C
– Power: 12VAC adaptor
– Dimension: 300 x 215 x 50mm
– Weight: approx. 1.3 kgs (meter only)
SET INCLUDES:
– 1 x Wall mount LED CO2, VOC, Temp & RH Monitor
– 1 x AC/DC adaptor
– English Operation Manual
– Standard factory Packaging
